Starter Roll Granulated Self-Adhered

EpiStrip™

Starter Roll Granulated Self-Adhered

EpiStrip™ Starter Roll Granulated Self-Adhered

EpiStrip Granulated Starter Roll is a self-adhering membrane that eliminates the need to cut shingle tabs.

It comes comes with a self adhering bottom and self sealing strip on the granulated side to prevent wind uplift at the edge. The self-adhering application allows fast installation, saving time and labor. The membrane is waterproof and self-sealing. It may be adhered directly to the roof deck or to most shingle underlayments

Uses: EpiStrip Granulated Starter Roll is used to replace the nailing of a three-tab shingle as the starter course. The adhesive compound self-seals around fasteners such as nails, screws and staples. Additionally, it easily sticks to common rood deck materials such as plywood, rigid foam insulation, metal and others

Technical Data

Test Properties Test Standard Typical Values
Unrollability ASTM D1970 No cracking, tearing or damage
Thickness Mils ASTM D 5147 (Nominal) 55 mils
Tensile Strength ASTM D 1970 MD32/CD27
Adhesion to Plywood LB/FT ASTM D 1970 -
40° F - 7.5
75° F - 14.6
Thermal Stability ASTM D 1970 250 F / Pass
Low Temperature Flexibility ICC AC 48 Pass
Tear Resistance LB/F ASTM D 1970 MD86/CD45
Permeability ASTM E 96 0.1
Nail Sealability ASTM D 1970 Pass
Specifications Data
Length Per Roll 33.5'
Width Per Roll 7.2"
No. of Rolls / Carton 6
Gr. Weight Per Carton 41 LBS
No. of Cartons Per Pallet 40
Gr. Weight Per Pallet 1760 LBS
